H25D-SS-5000-ABZC-28V/5-SM18, BEI Square Incremental Encoder Custom Replacement

This is a BEI square-shapedincremental encoderModel No. H25D-SS-5000-ABZC-28V/5-SM18.incremental encoderIt is also widely used, basically every month a few consulting customers. As we all know, BEI's encoders are also difficult to purchase now, and many dealers do not have goods in hand.

Three customers have already inquired about this product this month, and since the original is not available, we are introducing customized replacements here. In fact, we developed a customized replacement product at a very early stage. Using 1:1 parameters to realize the perfect parallel replacement. We always thought it was an ordinary encoder, so we didn't say it openly. Today, we will explain it in detail.

Customized alternative instructions

Let's take a look at the dimensions of this encoder, first of all this is a square flange, the shaft diameter is 9.52 mm. the original is marked in inches, 3/8 inch. The tab portion is 31.5mm. the number of pulses is: 5000, which is a relatively high number of pulses.

Let's start with our corresponding size parameter:

With this dimensional drawing we can see that this is a 1:1 mounting size with fully alternate application parameters.

Bottom line note: We have a complete line of customized replacement solutions. This product has done quite a few replacement applications over the years. It's basically a standard product for us.

Customization cycle and process

We will basically have some material stocked for this encoder alternative, which usually ships in about 7 days. It also depends on our scheduling.

The customization process of this product, directly send the model number to confirm. Some old models can not find the manual, according to the application parameters of communication to confirm. So much for these precautions, there is no other need to do the description of the place. In the use of parallel replacement, do not need to do more settings.

关于型号H25D-SS-5000-ABZC-28V/5-SM18编码器替代方案就介绍这么多吧。本身也没有多需要说明的地方，作为incremental encoder就这么些参数，总体来讲不复杂，算是比较容易实现的一个编码器方案。

Anyone who needs this encoder is welcome to contact us for assistance with application problems.
