Today we are going to record an oilWinch EncoderIt's this one.Avtron Encoders, Model: M6C-4S1HX51ZTZ00. this encoder was featured a long time ago, I just haven't written notes on it in this blog. This is one of the earliest and most numerous heavy duty incremental encoders we've ever done.
Speaking back to the epidemic period, in the special circumstances at that time, received a commission from an oil company to carry out the attack alternative custom development. This led to the later M6 series of various parameters of the customization service.
During the epidemic, the specifics were not known at the time, but it was just not possible to procure them. Some projects were affected and stalled. Against this background, an oil company contacted us to make a customized replacement of this encoder. the M6C-4S1HX51ZTZ00, was one of the first models to be replaced.
Description of Alternatives
So far, we have come out with 3 colors for the M6 series encoder replacements. The first one was silver, the second one was navy blue, and the current one is light blue. Nothing else has changed, only the three color numbers.
Let's take a look at the finished picture of the current replacement encoder:
Now with the new replacement encoder, which is strictly 1:1, you can directly substitute, almost all the same.
The highlights of this encoder are, firstly, the heavy duty encoder, then the shaft bore size is 25mm and the pulse is 1024ppr. These are the key parameters, and with these there is basically nothing left to verify.
A few years down the road, this alternative encoder is being used in a wider and wider area. It has been sent as far as Russia, the Middle East and other international oil-producing areas. For example, the famous Hafaya oil field has its figure.
Just this encoder products, we do not have mass production, all non-standard form of customization. Because the demand for this encoder is really too small, the overall procurement volume is very low, just to solve the application problems in the market to provide customized services. Therefore, we are not in stock, and no active circulation in the market, if it is urgent single need to pay attention to this article.
We don't know what kind of planning is done officially for this type of product that is in short supply. These products are so difficult to procure that many application companies have no place to buy spare parts. This encoder product is only a microcosm, there are many such encoders. Either the official production is discontinued or the procurement is difficult. In short, for the application of the enterprise is a problem.
In important industries, we provide relevant encoder customization services that we hope will be of some help. For commonly used encoders, we will help customize the replacement as much as possible. If there is a need, you can contact me to see if I can help you.
